Description
Inverter Charger SY-1.5K24 – Specifications
General
• Model Name / Number: SY-1.5K24
• Type: Hybrid Inverter Charger with MPPT Solar Controller
• Color: White and Black
• Operating Temperature Range: -10°C to 50°C
• Certifications: RoHS Compliant, CE
• Origin: Made in China
Inverter Mode
• Rated Power: 1500VA / 1500W
• Battery Voltage: 24VDC
• Battery Voltage Range: 21∼32VDC
• AC Output: 230VAC, 50/60Hz, 6.5A, 1Φ (single phase)
AC Charger Mode
• AC Input: 230VAC, 50/60Hz, 8.82A, 1Φ
• DC Output: 27VDC
• AC Output: 230VAC, 50/60Hz, 6.5A, 1Φ
• Maximum AC Charging Current: 40A
Solar Charger Mode
• Rated Power: 1200W
• Max. Solar Voltage (VOC): 150VDC
• MPPT Voltage Range: 30∼150VDC
• Maximum Solar Charging Current: 40A
Key Takeaways
• This is a 1.5kW 24V off-grid/hybrid inverter.
• Can run 1500W of continuous load.
• Built-in 40A AC charger + 40A MPPT solar charger, so it can charge your 24V batteries from both grid and solar.
• Supports up to 1200W of solar panels with voltage between 30V to 150V.
